Distance Distance diffuse 20 x 34 (C23) 20...100 mm ABS Teach button Laser class 1, red 650 nm

Operating range	20...100 mm
Switching frequency max.	1000 Hz
Sensing Linearity	± 0.25 mm
Supply voltage	13...30
Repeatability	< 0.25 mm
Polarity	PNP/NPN auto-detect
Output	Light-on/Dark-on + 1...10 V
Sensitivity adjustment	Teach button
Connection	M8 4-pin
Housing size [mm]	20 x 34 (C23)
Enclosure rating	IP 67 / IP 69K
Housing material	ABS
Resolution	0.12 mm
Temperature range	-20...+60°C
Light source	Laser class 1, red 650 nm
Operating principle	Distance diffuse

Type	Format
Datasheet
Operating manual
CE certificate
UKCA certificate

Distance Distance diffuse 20 x 34 (C23) 20...100 mm ABS Teach button Laser class 1, red 650 nm

Name: Distance Distance diffuse 20 x 34 (C23) 20...100 mm ABS Teach button Laser class 1, red 650 nm
Brand: Contrinex Group
SKU: DTL-C23PB-TMS-139-501
Price: 2060.0 RON
Availability: InStock

SKU: DTL-C23PB-TMS-139-501

Connection: M8 4-pin

Output: Light-on/Dark-on + 1...10 V

Polarity: PNP/NPN auto-detect

Variant

Price:

2.060 lei

Stock:

Re-stocking soon

Quantity:

Estimated Delivery Time 2-3 weeks

Share this product

Photoelectrics Sensor Distance-Distance-diffuse-20-34-C23-20100-mm-ABS-Teach-button-Laser-class-1-red-650-nm DTL-C23PB-TMS-139-501
