Short Specifications
DW-AV-701-M8-693
Operating range | 3 mm |
Switching frequency max. | 15 Hz |
Supply voltage | 10...30 |
Operating pressure [bar] | ≤ 100 bar |
Polarity | NPN |
Output | Normally Open (NO) |
Connection | PUR, 0.2 m, 3 wire + M12 4-pin |
Housing size [mm] | M8 |
Enclosure rating | IP 68 / IP 69K |
Housing material | ActivStone-Coated S.Steel V2A |
Temperature range | -25...+85°C |
Sensor Height | 45 mm |
Mounting | Embeddable |
Interface | Standard output |
3D CAD Library
Description
Inductives Sensor Weld-immune-Full-Inox-Series-700-ActivStone-Coated-SSteel-V2A-M8-Embeddable-3-mm-NPN DW-AV-701-M8-693
